Description
3.5 Features
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
17
Monitoring functions
Watchdog
Monitoring of program execution
Monitoring time can be parameterized in software
Restart can be parameterized in the event of a fault
Messages can be evaluated by an application program.
Status LEDs
POWER (internal power supply unit, PC switched On)
HDD (access to hard disk drive)
ETHERNET 1, ETHERNET 2 (Ethernet status,
"heartbeat")
PROFIBUS/MPI (activation display of the PROFIBUS/MPI
interface), optional product feature
SF PROFINET (status display of the CP 1616 onboard
interface), optional product feature
WATCHDOG (Watchdog function/error display)
TEMP (temperature status)
FAN (speed monitoring)
HDD1, HDD2 Alarm RAID status message in conjunction
with SIMATIC monitoring software (only with RAID option)
Basic variant
CPU motherboard Motherboard without fieldbus
Bus module 3 slots (2 x PCI, 1 x PCIe x16)
Processor Intel® Core™ i3-330E (2.13 GHz, 2 cores, 4 threads,
1066 MT/s FSB, 3 MB cache, EM64T, VT-x)
RAM expansion 1 GB SDRAM DDR3 1066 MT/sec (PC3-8500)
Single Channel without ECC
2 DIMM base for maximum of 8 GB (without or with ECC)
1)
Drives
Hard disks 250 GB SATA, 3.5", internal installation
Operating system without
1)
Memory expansions ≥4 GB can only be used in combination with 64-bit operating systems.
Optional accessories
Processor
Intel® Core™ i5-520E (2.4 GHz, 2 cores, 4 threads,
1066MT/s FSB, 3 MB cache, TB, EM64T, VT-x, VT-d,
AMT)
Intel® Core™ i7-610E, (2.53 GHz 2 cores, 4 threads,
1066MT/s FSB, 4 MB cache, TB, EM64T, VT-x, VT-d,
AMT)
RAM expansion Up to 8 GB, Dual Channel (without or with ECC)
1)
PROFIBUS/MPI 12 Mbps (isolated potential, compatible to CP 5611)
PROFINET 10/100 Mbps (CP 1616 onboard, three RJ-45)
Drives
CF drive Slot for Compact Flash card, on front
