12.1 BIOS beep codes
SIMATIC IPC647C
124 Operating Instructions, 12/2010, A5E02669337-02
Display
(hex)
Meaning Description Remedy
07H SEC_SETUP_CAR_OK Cache as RAM
test
Carry out RAM Test
on cache
Replacing a basic
module
08H SEC_FORCE_MAX_RATIO Tune CPU
frequency ratio
to maximum
level
Setting CPU
frequency
Service case
09H SEC_GO_TO_SECSTARTUP Setup BIOS
ROM cache
Set up BIOS ROM
cache
Service case
0AH SEC_GO_TO_PEICORE Enter Boot
Firmware
Volume
Calling up the boot
firmware memory
area
Service case
70H PEI_SIO_INIT Super I/O initial Initialization of the
Super I/O
Service case
71H PEI_CPU_REG_INIT CPU Early Initial Initialize CPU
Register
Service case
72H PEI_CPU_AP_INIT Multi-processor
Early initial
Multi processor
initialization
Service case
73H PEI_CPU_HT_RESET HyperTransport
initial
Initialize Hyper
Transport functionality
Service case
74H PEI_PCIE_MMIO_INIT PCIE MMIO
BAR Initial
Initialize PCIE
Register
Service case
75H PEI_NB_REG_INIT North Bridge
Early Initial
Initialization of the
North bridge
Service case
76H PEI_SB_REG_INIT South Bridge
Early Initial
Initialization of the
South bridge
Service case
77H PEI_PCIE_TRAINING PCIE Training Training phase of the
PCIE device
Service case
79H PEI_SMBUS_INIT SMBUS Early
Initial
Initialization of the SM
Bus
Service case
41H DXE_SB_SPI_INIT South bridge
SPI initial
Initialization of the
Serial Peripheral
Interface in the South
Bridge
Service case
42H DXE_CF9_RESET Setup Reset
service,
DXE_CF9Reset
Setup Reset service Service case
43H DXE_SB_SERIAL_GPIO_INIT South bridge
Serial GPIO
initial,
DXE_SB_Serial
GPIO_INIT
Initializations of the
serial GPIO
Service case
44H DXE_SMMACCESS Setup SMM
ACCESS
service
Setup SMM access
service
Service case
45H DXE_NB_INIT North bridge
Middle initial
Initialization of the
North Bridge
Service case
46H DXE_SIO_INIT Super I/O DXE
initial
Initialization of the
Super IO
Service case
