Alarm, error, and system messages
12.1 BIOS beep codes
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
127
Display
(hex)
Meaning Description Remedy
1BH BDS_CONNECT_USB_DEVICE USB device
driver initial
Initialize USB device
driver
Service case
1CH BDS_NO_CONSOLE_ACTION Console device
initial fail
Initialization of the
console faulty
Service case
1DH BDS_DISPLAY_LOGO_SYSTEM_INFO Display logo or
system
information
Display logo or
system information
Service case
1EH BDS_START_IDE_CONTROLLER IDE controller
initial
Initialization of the
IDE controller
Service case
1FH BDS_START_SATA_CONTROLLER SATA controller
initial
Initialization of the
SATA controller
Service case
20H BDS_START_ISA_ACPI_CONTROLLER SIO controller
initial
Initialization of the
Super IO
Service case
21H BDS_START_ISA_BUS ISA BUS driver
initial
Initialization of the
ISA bus driver
Service case
22H BDS_START_ISA_FDD Floppy device
initial
Initialization of the
floppy connection
Service case
23H BDS_START_ISA_SERIAL Serial device
initial
Initialization of the
serial connection
Service case
24H BDS_START_IDE_BUS IDE device initial Initialization of the
IDE connection
Service case
25H BDS_START_AHCI_BUS AHCI device
initial
Initialization of the
AHCI connection
Service case
56H DXE_RELOCATE_SMBASE Relocate SMM
BASE
Reassign SMM base Service case
57H DXE_FIRST_SMI SMI test SMI test Service case
58H DXE_VTD_INIT VTD Initial Initialize I/O
virtualization (VTD)
Service case
59H DXE_BEFORE_CSM16_INIT Legacy BIOS
initial
Legacy BIOS
initialization
Service case
5AH DXE_AFTER_CSM16_INIT Legacy interrupt
function initial
Legacy interrupts
initialization
Service case
5BH DXE_LOAD_ACPI_TABLE ACPI Table
Initial
ACPI table
initialization
Service case
5CH DXE_SB_DISPATCH Setup SB SMM
Dispatcher
service,
DXE_SB_Dispat
ch
SMM dispatcher
service
Service case
5DH DXE_SB_IOTRAP_INIT Setup SB
IOTRAP Service
SouthBridge IOTRAP
service
Service case
5EH DXE_SUBCLASS_DRIVER Build AMT Table Initialization of the
AMT (Active
Management
Technology) table
Service case
5FH DXE_PPM_INIT PPM Initial Initialization of the
Processor Power
Management
Service case
