Dimension drawings
15.1 Dimensional drawing of the device
SIMATIC IPC647C
144 Operating Instructions, 12/2010, A5E02669337-02
481,4
465 8,2
87,6
76,25,7
430
487,1
444,6
Alle Angaben in mm.
Figure 15-1 Dimensions IPC647C
