Detailed descriptions
16.1 Motherboard
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
163
Signal Pin no. Pin no. Signal
PCIEX16_TX_P(15) B14 A14 PCIE0_ECLK_N
PCIEX16_TX_N(15) B15 A15 GND
GND B16 A16 PCIEX16_RX_P(15)
SDVO_CTRLCLK B17 A17 PCIEX16_RX_N(15)
GND B18 A18 GND
PCIEX16_TX_P(14) B19 A19 n.c.
PCIEX16_TX_N(14) B20 A20 GND
GND B21 O21 PCIEX16_RX_P(14)
GND B22 A22 PCIEX16_RX_N(14)
PCIEX16_TX_P(13) B23 A23 GND
PCIEX16_TX_N(13) B24 A24 GND
GND B25 A25 PCIEX16_RX_P(13)
GND B26 A26 PCIEX16_RX_N(13)
PCIEX16_TX_P(12) B27 A27 GND
PCIEX16_TX_N(12) B28 A28 GND
GND B29 A29 PCIEX16_RX_P(12)
n.c. B30 A30 PCIEX16_RX_N(12)
SDVO_CTRLDATA B31 A31 GND
GND B32 A32 n.c.
PCIEX16_TX_P(11) B33 A33 n.c.
PCIEX16_TX_N(11) B34 A34 GND
GND B35 A35 PCIEX16_RX_P(11)
GND B36 A36 PCIEX16_RX_N(11)
PCIEX16_TX_P(10) B37 A37 GND
PCIEX16_TX_N(10) B38 A38 GND
GND B39 A39 PCIEX16_RX_P(10)
GND B40 A40 PCIEX16_RX_N(10)
PCIEX16_TX_P(9) B41 A41 GND
PCIEX16_TX_N(9) B42 A42 GND
GND B43 A43 PCIEX16_RX_P(9)
GND B44 A44 PCIEX16_RX_N(9)
PCIEX16_TX_P(8) B45 A45 GND
PCIEX16_TX_N(8) B46 A46 GND
GND B47 A47 PCIEX16_RX_P(8)
MCH_CFG_20 B48 A48 PCIEX16_RX_N(8)
GND B49 A49 GND
PCIEX16_TX_P(7) B50 A50 n.c.
PCIEX16_TX_N(7) B51 A51 GND
GND B52 A52 PCIEX16_RX_P(7)
GND B53 A53 PCIEX16_RX_N(7)
PCIEX16_TX_P(6) B54 A54 GND
PCIEX16_TX_N(6) B55 A55 GND
