Description
3.6 Installation
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
25
Front status displays
GREEN Data traffic
OFF
No connection
No data traffic
ETHERNET 2 * ETHERNET status
display
GREEN Data traffic
OFF
No connection
No data traffic
PROFIBUS/MPI
(optional)
Display of the
communication status to
S7 or PROFIBUS
GREEN Data traffic
OFF
CP not available
CP disabled
No error, communication
established
Charging in progress
CP 1616 driver not installed
CP in NDIS mode
Flashes slowly
Link status error
IO controller: IO device cannot
be addressed
IO controller: Duplicate IP
address
Flashes rapidly Exception error: diagnostics via
Web or SNMP is no longer
possible
SF PROFINET
(optional)
Status display for
CP 1616 onboard
AN
Diagnostics information
available
No communication
established.
OFF WATCHDOG not activated
GREEN WATCHDOG monitoring enabled
WATCHDOG WATCHDOG status
display
RED Monitoring time elapsed
OFF Internal temperature OK TEMP Internal temperature
monitoring
RED Internal temperature critical
OFF Fan speed OK FAN Fan status (only with
active SOM or
DiagMonitor software)
RED Fan speed too low
OFF RAID is OK
One RED HDD1 or HDD2 not OK
Both RED RAID not OK
(for information on locating the
hard disk, refer to the
2RAID
system (Page 247) section)
HDD1 ALARM
HDD2 ALARM
Hard disk alarm in
conjunction with RAID
and monitoring software
Both flash RAID is synchronized
All displays are lit Error in early BIOS Post All lit CPU startup failure
Error in early POST
* LAN interfaces are numbered on the enclosure to provide unique identification. The numbering by
the operating system may deviate from this.
