Service and maintenance
11.1 Removing and installing hardware components
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
99
Replacing the battery
Procedure:
How to replace the battery
1. Open the device and, if necessary,
remove the bus frame. See
6Installation and removal of the bus
frame (Page
371)
2. Remove the old battery from the
socket. Make sure you do not use
metal objects for this.
3. Applying a slight pressure, press the
new battery into the socket. Make
sure you do not use metal objects for
this. Make sure not to short-circuit the
battery during handling.
4. Close the device.
