09/02 Configuration

CP 243-1

J31069-D0428-U001-A1-7618

Defining the memory area for storing the configuration

Finally, use the next mask to define the memory area in which your configuration

data are to be stored on the S7-200 CPU. The Wizard will assist you in doing so.

The Wizard then informs you about which subroutines it is establishing on the ba-

sis of your configuration and where your configuration data are being stored.

Configuration of the system is now complete.

Attention

Ensure that the memory area in which the Ethernet Wizard stores the configuration

data are not used by your S7-200 user program.
