Siemens SIMATIC NET CP 243-1 User Manual

09/02 Diagnostics
CP 243-1
J31069-D0428-U001-A1-7618
63
Error byte Return
mechanism
hex dec
Description Reaction / remedy
Byte
offset
in SM
area
Return
value
(ETHx_)
16#84 132 A command with an unallowable
data block number was started.
A new read/write command can
be initiated
The user program should be
checked
_XFR
Table 15: Error messages (error byte)
Error word Return mecha-
nism
hex dec
Description Reaction / troubleshooting
Byte
offset
in SM
area
Return
value
(ETHx_)
16#0001 1 Timeout on the S7 bus Automatic warm start 20,21 _CTRL
16#000D 13 All data transmissions were
aborted because a reconfigura-
tion was initiated by the user
program.
Restart of the system 20,21 _CTRL
16#0030 48 The configuration could not be
called up from the CPU within a
specified time period.
Automatic warm start 20,21 _CTRL
16#0031 49 A syntactically correct CDB
configuration was not found in
the S7-200 CPU memory.
20,21 _CTRL
16#0032 50 The CRC checksum of the con-
figuration data (CDB, NDB) is
incorrect.
20,21 _CTRL
16#0033 51 The configuration data for the
CP 243-1 are faulty or incor-
rectly stored.
20,21 _CTRL
16#0034 52 The pointer to the CDB is faulty
or no CDB is loaded.
Ensure that the ETHx_CTRL
subroutine is called up at the
beginning of the user pro-
grams.
Check the CDB pointer (byte
offset 46 in the SM memory
area)
20,21 _CTRL
