Diagnostics 09/02
CP 243-1
58 J31069-D0428-U001-A1-7618
Byte offset in
SM area
Meaning Format
0-15 Module type 16 byte
ASCII
16-19 Software version 4 byte
ASCII
20-21 Error code (see Chapter 6.2) 2 byte hex
22 Status CP 243-1
Bit [0]
0: CP 243-1 not booting
1: CP 243-1 booting
Bit [1]
0: BOOTP sequence not executed
1: BOOTP sequence is being executed
Bit [2]
0: CP 243-1 not ready for operation
1: CP 243-1 ready for operation
Bit [3]
0: STEP 7 Micro/Win 32 not enabled
1: STEP 7 Micro/Win 32 enabled
Bit [4]
0: Configuration accord. to CDB
1: No valid configuration in CDB
Bit [5] Reserved
Bit [6]
0: No Ethernet connection
1: CP 243-1 connected to Ethernet
Bit [7]
0: No error in CP 243-1
1: CP 243-1 in error state
1 byte hex
23 Reserved
24 Hardware version 1 byte
ASCII
Table 13: Global errors and their error codes
