Siemens SIMATIC NET CP 243-1 User Manual

Programming 09/02
CP 243-1
52 J31069-D0428-U001-A1-7618
Return parameters:
Name Type Meaning
CP_Ready BOOL Status of CP 243-1
0: CP not ready for operation
1: CP ready for operation
CH_Ready WORD Status of individual channels
Bit 0 corresponds to Channel 0
Bit 1 corresponds to Channel 1
Bit 2 corresponds to Channel 2
Bit 3 corresponds to Channel 3
Bit 4 corresponds to Channel 4
Bit 5 corresponds to Channel 5
Bit 6 corresponds to Channel 6
Bit 7 corresponds to Channel 7
0: Channel is not ready
1: Channel is ready
Error WORD Error code
0x0000: No error occurred
other: Error (description: see Chapter 6.2)
Table 8: Return parameters (ETHx_CTRL)
A value of 1 in a bit of the CH_Ready return parameter indicates that the associ-
ated channel is ready. This means that a communication connection to the partner
defined in the configuration can be established with the communication parameters
specified there (IP address, TSAPs, ...).
