09/02 Diagnostics
CP 243-1
J31069-D0428-U001-A1-7618
65
Error word Return mecha-
nism
hex dec
Description Reaction / troubleshooting
Byte
offset
in SM
area
Return
value
(ETHx_)
16#0098 152 The specified Gateway ad-
dress was not accepted by the
TCP/IP stack.
Automatic warm start 20,21 _CTRL
16#00F0 240 The CP 243-1 was not recog-
nized by the S7-200 CPU
Check the configuration and
the structure of the S7-200
system
_CTRL
16#00F1 241 The address of the output byte
over which the CP 243-1 should
be accessible according to the
configuration is not compatible
with the actual position of the
CP 243-1 in the S7-200 system.
Check the configuration and
the structure of the S7-200
system
_CTRL
16#0100
to
16#0108
256
to
264
A timeout was found on the S7
bus
Automatic warm start 20,21 _CTRL
16#8080 32896 CP 243-1 has not yet finished
booting
Check 24 V voltage supply if
necessary
20,21 _CTRL
Table 16: Error messages (error word)
