Diagnostics 09/02
CP 243-1
64 J31069-D0428-U001-A1-7618
Error word Return mecha-
nism
hex dec
Description Reaction / troubleshooting
Byte
offset
in SM
area
Return
value
(ETHx_)
16#0035 53 The transmitted configuration
has an invalid format code
20,21 _CTRL
16#0036 54 TSAPs are not well-defined or
are present more than once in
the configuration
20,21 _CTRL
16#0038 56 The configuration is not well-
defined (IP addresses are
faulty, neither the clients nor the
server are configured, channel
for STEP 7 Micro/WIN 32 is not
enabled)
20,21 _CTRL
16#003A 58 The module name for the
CP 243-1 in the configuration
was changed.
20,21 _CTRL
16#003B 59 The configuration contains an
invalid IP address
20,21 _CTRL
16#003C 60 The configuration contains an
invalid Gateway address
20,21 _CTRL
16#003D 61 The configuration contains an
invalid value in the "Keep Alive"
parameter
20,21 _CTRL
16#003E 62 A valid configuration was not
received, neither from the S7-
200 CPU memory nor via
BOOTP
Cyclical attempt to receive a
valid configuration either from
the S7-200 CPU memory or
via a BOOTP server
20,21 _CTRL
16#0042 66 The NDB contains syntactically
incorrect read/write commands
or length specifications.
20,21 _CTRL
16#0093 147 The BOOTP command failed Automatic warm start 20,21 _CTRL
16#0094 148 The BOOTP server contains in-
valid data
Automatic warm start 20,21 _CTRL
16#0095 149 The specified Keep Alive time
was not accepted by the
TCP/IP stack.
Automatic warm start 20,21 _CTRL
16#0096 150 The specified IP address for a
client was not accepted by the
TCP/IP-Stack.
Automatic warm start 20,21 _CTRL
16#0097 151 The specified subnet mask was
not accepted by the TCP/IP
stack.
Automatic warm start 20,21 _CTRL
