Siemens SIMATIC NET CP 243-1 User Manual

Diagnostics 09/02
CP 243-1
62 J31069-D0428-U001-A1-7618
Error byte Return
mechanism
hex dec
Description Reaction / remedy
Byte
offset
in SM
area
Return
value
(ETHx_)
16#08 8 The write command failed A new read/write command can
be initiated.
The parameters of the corre-
sponding write command
should be checked.
25 - 32 _XFR
16#09 9 Channel not configured A new read/write command with
other parameters can be initi-
ated.
25 - 32 _XFR
16#0A 10 Although the channel is configured
as a SERVER, an attempt was
made to initiate a read/write com-
mand
A new read/write command with
other parameters can be initi-
ated.
25 - 32 _XFR
16#0B 11 Preceding read/write command not
yet completed
A new read/write command can
be initiated.
Evaluate the "DONE" return pa-
rameter of the preceding
read/write command
25 - 32 _XFR
16#0C 12 Invalid command code A new read/write command can
be initiated
25 - 32 _XFR
16#0D 13 All data transmissions were
aborted because a reconfiguration
was initiated by the user program.
Restart of the system 25 - 32
33
_XFR
_CFG
16#80 128 There is no 24 V external supply
voltage
Wait until ready 25 - 32
33
16#81 129 The channel being used is not
ready or is not operating properly
Wait until ready
Evaluation of the return pa-
rameters of the ETHx_CTRL
subroutine
_XFR
_CFG
16#82 130 The channel being used is busy Wait until ready _XFR
_CFG
16#83 131 A command with an unallowable
channel number was started
A new read/write command can
be initiated
The user program should be
checked
_XFR
