Siemens SIMATIC NET CP 243-1 User Manual

Configuration 09/02
CP 243-1
40 J31069-D0428-U001-A1-7618
Byte offset in
variables mem-
ory
Description Data format Example
45-46 Remote TSAP 2 bytes hex See S7 connection 0
section.
S7 connection 2 section (If not all bytes are used in this section, they should be filled in with
16#00)
47 Flag byte
See S7 connection 0 section.
1 byte hex See S7 connection 0
section.
48-49 IP address of partner
See S7 connection 0 section.
4 bytes hex See S7 connection 0
section.
52-53 Local TSAP 2 bytes hex 16#1200
54-55 Remote TSAP 2 bytes hex See S7 connection 0
section.
S7 connection 3 section (If not all bytes are used in this section, they should be filled in with
16#00)
56 Flag byte
See S7 connection 0 section.
1 byte hex See S7 connection 0
section.
57-60 IP address of partner
See S7 connection 0 section.
4 bytes hex See S7 connection 0
section.
61-62 Local TSAP 2 bytes hex 16#1300
63-64 Remote TSAP 2 bytes hex See S7 connection 0
section.
S7 connection 4 section (If not all bytes are used in this section, they should be filled in with
16#00)
65 Flag byte
See S7 connection 0 section.
1 byte hex See S7 connection 0
section.
66-69 IP address of partner
See S7 connection 0 section.
4 bytes hex See S7 connection 0
section.
70-71 Local TSAP 2 bytes hex 16#1400
72-73 Remote TSAP 2 bytes hex See S7 connection 0
section.
S7 connection 5 section (If not all bytes are used in this section, they should be filled in with
16#00)
74 Flag byte
See S7 connection 0 section.
1 byte hex See S7 connection 0
section.
75-78 IP address of partner
See S7 connection 0 section.
4 bytes hex See S7 connection 0
section.
79-80 Local TSAP 2 bytes hex 16#1500
81-82 Remote TSAP 2 bytes hex See S7 connection 0
section.
