15.6 Communication services
CPU 410-5H Process Automation
242 System Manual, 09/2014, A5E31622160-AB
15.6
Communication services
15.6.1
Overview of communication services
Overview
Table 15- 4 Communication services of the CPUs
Communication service
Functionality
Allocation of S7 connection
resources
Via DP
Via
PN/IE
PG communication
Commissioning, testing, diagnostics
Yes
Yes
Yes
OP communication
Operator control and monitoring
Yes
Yes
Yes
S7 communication Data exchange via configured connec-
tions
Yes Yes Yes
Routing of PG functions For example, testing, diagnostics be-
yond network boundaries
Yes Yes Yes
PROFIBUS DP Data exchange between master and
slave
No Yes No
PROFINET IO Data exchange between I/O controllers
and I/O devices
No No Yes
SNMP
(Simple Network Manage-
ment Protocol)
Standard protocol for network diagnos-
tics and parameter assignment
No No Yes
Open communication over
TCP/IP
Data exchange over Industrial Ethernet
with TCP/IP protocol (with loadable
FBs)
Yes No Yes
Open communication over
ISO on TCP
Data exchange over Industrial Ethernet
with ISO on TCP protocol (with
loadable FBs)
Yes No Yes
Open communication over
UDP
Data exchange over Industrial Ethernet
with UDP protocol (with loadable FBs)
Yes No Yes
Data record routing For example, parameter assignment
and diagnostics of field devices on
PROFIBUS DP with PDM.
Yes Yes Yes
Note
Communication via an PNIO interface
If you want to use an PNIO interface of the module for communication in system operation,
you must also network this in Step 7 / HW Config / NetPro.
