Structure of the CPU 410-5H
3.1 Operator controls and display elements on the CPU 410-5H
CPU 410-5H Process Automation
System Manual, 09/2014, A5E31622160-AB
37
Slot for synchronization modules
You can insert one synchronization module into this slot. See section Synchronization
modules (Page 201).
You can connect the distributed I/O to the PROFIBUS DP interface.
The PROFINET IO interfaces establish the connection to Industrial Ethernet. The
PROFINET IO interfaces also serve as the access point for the engineering system. The
PROFINET IO interfaces feature two switched ports with external connectors (RJ 45). You
will find additional information about PROFINET IO in the sections PROFINET IO systems
(Page 97).
Connecting only to Ethernet LAN
These interfaces only allow connection to an Ethernet LAN. You cannot connect them to
the public telecommunication network, for example.
You may only connect PROFINET IO-compliant network components to this interface.
