Siemens SIMATIC RF185C User Manual

Programming via OPC UA
10.2 OPC UA variables
SIMATIC RF185C, RF186C, RF188C, RF186CI, RF188CI
Operating Instructions, 04/2020, C79000-G8976-C512-03
125
Table 10- 10 RfPower
Path
Root/Objects/DeviceSet/Read_point_x/RuntimeParameters/RfidS
ettings/Antennaxx/RfPower
Data type
SByte
Access
R/W
Description
Radiated power of the antenna
Possible values
0 … 127
The special features of the different reader types are described
below:
With RF380R:
• 2: 0.5 W
• 3: 0.75 W
• 4: 1.0 W
• 5: 1.25 W
• 6: 1.5 W
• 7: 1.75 W
• 8: 2.0 W
Settings outside the specified values mean that the default value
of 1.25 W is used.
For UHF readers:
Radiated power of the antenna in [dB]
• 0
• 5 ... 33
Settings outside of the specified values are set to the respective
area limits (1-4 ⇒ 5; 34-127 ⇒ 33).
10.2.6 Diagnosis
These variables serve diagnostics and tracking purposes of the plant via OPC UA. You can
use these variables both with an OPC UA application and with a PROFINET application as
main application.
Requirements
● OPC UA application
For the diagnostics values to be available also in the case of an OPC UA application as
main application, the "Diagnostics" option needs to be set in WBM.
● PROFINET, PROFIBUS, EtherNet/IP or XML application
For an OPC UA client to be able to connect in addition in case of a PROFINET,
PROFIBUS, EtherNet/IP or XML application as the main application, the "Parallel" option
needs to be enabled in the WBM. In this case, the Diagnostics option is automatically
enabled as well. Please note that write access is no longer possible for OPC UA clients
as soon as the "Parallel" option is set.
