Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF185C, RF186C, RF188C, RF186CI, RF188CI
80 Operating Instructions, 04/2020, C79000-G8976-C512-03
Click the button to add new events. Click the button to remove already specified
events.
Table 7- 9 Description of the events
Transponder
If a transponder was successfully processed by the selected read point, the
output is changed to the state specified here.
Input change If the state at the selected digital input changes, the output is set to the state
specified here.
Output change If the state at the selected digital output changes, the output is set to the state
Note
Reaction time of the digital outputs
N
ote that the reaction time of the digital outputs (and inputs) depends on the CM load and is
- 100 ms on average.
Note the following properties of the digital outputs:
● The outputs are only changed once when the event occurs.
The outputs remain set unchanged even when the event is no longer pending.
● Pending events have no effect on the output.
7.3.5 The "Settings - Communication" menu item
The "Settings - Communication" menu item is divided into the following tabs.
● Network interfaces
● PLC
● XML
● OPC UA
In the "Network interfaces" tab, you can enable/disable the network ports, SNMP and NTP
protocols. You can disable STEP 7 access in the "PLC" tab. In the "OPC UA" tab, you can
enable and edit the OPC UA server function of the communication module.
