Service and maintenance
12.1 Diagnostics
SIMATIC RF185C, RF186C, RF188C, RF186CI, RF188CI
Operating Instructions, 04/2020, C79000-G8976-C512-03
153
12.1.7 Diagnostics using Studio 5000 Logix Designer
This section is intended only for users of Rockwell controllers.
You will find information on diagnostics using the Studio 5000 Logix Designer in the Studio
5000 Logix Designer manual.
12.1.8 Parameterization of the diagnostics
With STEP 7 Basic / Professional, you can select which diagnostic interrupt messages you
wish to view. Follow the steps below to deactivate the diagnostic interrupt messages:
● Communication module:
Select communication module
"General > Module parameters > Diagnostic interrupt"
● Connected readers:
Select communication module
"Device view > Device overview > Reader module > General > Module parameters >
Diagnostics messages"
Diagnostic interrupts/messages
Diagnostic interrupts (communication module diagnostics)
If the diagnostic interrupt has been activated ("On"), the following diagnostic interrupts are
reported:
● Fault in power supply
● Hardware fault
● Firmware error
