Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF185C, RF186C, RF188C, RF186CI, RF188CI
Operating Instructions, 04/2020, C79000-G8976-C512-03
97
7.3.7 The "Diagnostics - Log" menu item
The log of the communication module is displayed in the "Diagnostics - Log" menu item.
Figure 7-13 The "Diagnostics - Log" menu item
The menu item "Log" shows all message types that were selected in the menu item "Settings
- General" in the "Log settings" area. This menu item documents the actions performed by
the communication module.
The entries contain the following properties:
Table 7- 22 Displayed properties of the log messages
Date/time Time stamp when the entry was made by the communication module.
Note that the time stamp is generated by the device clock (UTC time). This
time is compared with the time zone set on the PC and displayed accordingly.
Type Type of message
Which message types are signaled depends on the check boxes enabled in
the menu item "Settings - General" in the "Log settings" area.
