Siemens SIMATIC S5 Series User Manual

6
6-10
Working with S5-DOS/ST
C79000-G8576-C760-03
FTARC is ready when the main menu shows the status
“connected” (in the message line at the bottom of the screen).2.
F T A R C File Transfer Program Version 1.4
Status: connected
Filename specification
Send mode
Receive mode
Preset drives
Exit this program
F1 
F3 
F5 
F8 
*.*
local: PG7x0 #193 MS-DOS C:\DOS
remote: PG7x0 # 88 MS-DOS C:\
Do not make any inputs at the remote partner device, make your
entries for the program at the local device.
In the field “Filename specification:”, you can restrict the file
names which are to be shown in the menu if you wish. To do this
overwrite the default *.* (all files) with the required filter, for
example, *.txt.
You can use alphanumeric characters, the period “.” and the
wildcards “*” and “?”. You cannot, however, use the drive
identifiers or complete path names. These must be specified in the
menu “Preset drives”.
Main Menu
Filename
Specification
(Filter for File
Names)
File Transfer

Siemens SIMATIC S5 Series Specifications

General

Series	SIMATIC S5
Manufacturer	Siemens
Category	Controller
Programming Language	STEP 5
Modular Design	Yes
Power Supply	24V DC
Communication Interfaces	RS-232, RS-485
Memory Type	EPROM, RAM
Digital Inputs/Outputs	Varies depending on module configuration
Analog Inputs/Outputs	Varies depending on module configuration
CPU Type	Varies by model
Memory	Varies by model
Operating Temperature	0°C to 60°C
