Siemens SIMATIC S5 Series User Manual

6
6-11
Working with S5-DOS/ST
C79000-G8576-C760-03
In the lower part of the main menu the working area set is
displayed;
local: ... “drive: path /” for the local device and
remote: ...“drive: path /” for the remote device
To set the drive/path required, select the corresponding menu via
the function key F5. You will find more details in the section
“Selecting the Preset Drives” on page 6-12.
If the correct drive/path for the local and remote devices is
displayed in the main menu, select either
F1 Send mode (local → remote) or
F3 Receive mode (remote → local)
to get the relevant menu for the function.
More details can be found in the section “Send Mode and Receive
Mode” on page 6-13.
You exit the FTARC program with the function key F8.
Preset Drives
(Function Key F5)
Send
Mode/Receive
Mode (Function
Keys F1/F3)
Exit this Program
(Function Key F8)
File Transfer

Siemens SIMATIC S5 Series Specifications

General

Series	SIMATIC S5
Manufacturer	Siemens
Category	Controller
Programming Language	STEP 5
Modular Design	Yes
Power Supply	24V DC
Communication Interfaces	RS-232, RS-485
Memory Type	EPROM, RAM
Digital Inputs/Outputs	Varies depending on module configuration
Analog Inputs/Outputs	Varies depending on module configuration
CPU Type	Varies by model
Memory	Varies by model
Operating Temperature	0°C to 60°C
