Siemens SIMATIC S5 Series User Manual

6
6-12
Working with S5-DOS/ST
C79000-G8576-C760-03
You can modify the standard settings for drive and path for the
local and remote device by selecting the function F5 “Preset
drives”.3.
F T A R C File Transfer Program Version 1.4
Status: connected
F1 
F8 
local: PG7xx #193 MS-DOS C:\
remote: PG7xx # 88 MS-DOS C:\
Make preset
valid and
return to
main menu
Switch local/remote
Preset drives
Local drive:
Local path:
Remote drive:
Remote path:
A B C D E F G
\TEST
A B C
\
In this submenu FTARC first displays the names of the drives
permitted and the path set for the current drive (shown in reverse
video) for the local device.
With the function key F1 you select the device (local or remote)
for which you wish to modify the drive/path. The line selected for
the device currently selected is shown in reverse video (for
example, “Local/remote drive” or “Local/remote path”).
Use the cursor keys “cursor left/cursor right” to select the drive
you require.
Use the cursor key “cursor down” to move to the selection for
path/user area.
Selecting the
Preset Drives
Selecting the
Device
Selecting a Drive
File Transfer
