Siemens Simatic S7-200 CPU 210 User Manual

A-5
S7-200 Programmable Controller, CPU 210
C79000-G7076-C235-01
ML+
24V DC
Inputs (15 to 35 VDC)
Outputs (20.4 to 28.8 VDC)
+
3.3K ohms
470 ohms
Power Supply
Note: Actual component values may vary.
DC
OUTPUTS
36V
36V
+
+
M L+ 0.0 0.1 0.2 0.3
1M 0.0 0.1 0.2 0.3 M L+
DC INPUTS
24 V DC OUT
24 VDC Power for
Input Sensors
Analog Adjustment
Potentiometer
Location for the
Memory Cartridge
Figure A-1 Connector Terminal Identification for CPU 210 DC/DC/DC
