5-2
S7-200 Programmable Controller, CPU 210
C79000-G7076-C235-01
5.1 Valid Ranges for the CPU 210 and PDS 210
Valid Operand Ranges
Table 5-1 provides the valid ranges of the operands used to access data in the different
memory areas. These ranges vary according to the size of the data being accessed.
Table 5-1 Operand Ranges
Access Method
CPU 210 and PDS 210
Bit Access
(Byte.bit)
I 0.0 to 0.3
Q 0.0 to 0.3
M 0.0 to 5.7
SM 0.0 to 1.7
Word Access T 0 to 3
C 0 to 3
MW 0 to 4
SMW 0 to 2
Constant
Instruction Set
