Siemens SIMATIC S7-300 Module data Technical Data

Technical data of CPU 31x
7.7 CPU 317-2 PN/DP
CPU 31xC and CPU 31x, Technical data
7-36 Manual, Edition 08/2004, A5E00105475-05
Technical data
• Number of variables
– Of those as status variable
– Of those as control variable
30
Max. 30
Max. 14
Forcing
• Variables
Inputs/Outputs
• Number of variables
Max. 10
Block status Yes
Single step Yes
Breakpoints 2
Diagnostic buffer Yes
• Number of entries (not configurable)
Max. 100
Communication functions
Open IE communication via TCP/IP Yes (via integrated PROFINET interface and
loadable FBs, max. 8 connections)
PG/OP communication
Global data communication Yes
• Number of GD circuits
8
• Number of GD packets
– Sending stations
– Receiving stations
Max. 8
Max. 8
Max. 8
• Length of GD packets
– Consistent data
max. 22 bytes
22 bytes
S7 basic communication Yes
• User data per request
– Consistent data
max. 76 bytes
76 bytes
S7 communication Yes
• As server
Yes
• as client
Yes (via integrated PN interface and loadable
FBs, or even via CP and loadable FBs)
• User data per request
– Consistent data
See the STEP 7 Online Help,
Common
parameters of SFBs/FBs and SFC/FC of the S7
communication)
S5-compatible communication Yes (via CP and loadable FCs)
Number of connections 32
can be used for
• PG communication
– Reserved (default)
– Configurable
Max. 31
1
1 to 31
• OP communication
– Reserved (default)
– Configurable
Max. 31
1
1 to 31
• S7-based communication
– Reserved (default)
– Configurable
Max. 30
0
0 to 30

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
