Technical data of CPU 31xC
6.6 Technical data of the integrated I/O
CPU 31xC and CPU 31x, Technical data
Manual, Edition 08/2004, A5E00105475-05
6-39
6.6.3 Configuration
Introduction
You configure the integrated I/O of CPU 31xC with STEP 7. Always make these settings
when the CPU is in STOP. The generated parameters are downloaded from the PG to the
S7-300 and written to CPU memory .
You can also choose to change the parameters at SFC 55 in the user program (see the
Reference Manual
System and Standard Functions ). Refer to the structure of record 1 for
the respective parameters.
Parameters of standard DI
The table below gives you an overview of the parameters for standard digital inputs.
Table 6-7 Parameters of standard DI
Parameters Value range Default Range of efficiency
Input delay (ms) 0,1/0,5/3/15 3 Channel group
The table below gives you an overview of the parameters when using digital inputs as
interrupt inputs.
Table 6-8 Parameters of the interrupt inputs
Parameters Value range Default Range of efficiency
Interrupt input Disabled /
positive edge
disabled digital input
Interrupt input Disabled/
negative edge
disabled digital input

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
