Communication
3.4 DPV1
CPU 31xC and CPU 31x, Technical data
Manual, Edition 08/2004, A5E00105475-05
3-33
Interrupt blocks with DPV1 functionality
Table 3-13 Interrupt blocks with DPV1 functionality
OB Functionality
OB 40 Process interrupt
OB 55 Status interrupt
OB 56 Update interrupt
OB 57 Vendor-specific interrupt
OB 82 Diagnostic interrupt
Note
You can now also use organizational blocks OB40 and OB82 for DPV1 interrupts.
System blocks with DPV1 functionality
Table 3-14 System function blocks with DPV1 functionality
SFB Functionality
SFB 52 Read data record from DP slave or centralized module
SFB 53 Write data record to DP slave or centralized module
SFB 54 Read additional alarm information from a DP slave or a centralized module in the
relevant OB.
SFB 75 Set any interrupts for intelligent slaves
Note
You can also use SFB 52 to SFB 54 for centralized I/O modules. SFBs 52 to 54 can also be
used for PN IO.
Reference
For further information on the blocks mentioned earlier, refer to the reference manual
System Software for S7-300/400: System and Standard Software , or directly to the
STEP 7 Online Help .
See also
PROFIBUS DP (Page 3-2)

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
