Siemens SIMATIC S7-300 Module data Technical Data

Technical data of CPU 31x
7.7 CPU 317-2 PN/DP
CPU 31xC and CPU 31x, Technical data
7-38 Manual, Edition 08/2004, A5E00105475-05
Technical data
MPI
Services
• PG/OP communication
Yes
• Routing
Yes
• Global data communication
Yes
• S7 basic communication
Yes
• S7 communication
– As server
– As client
Yes
Yes
No (but via CP and loadable FBs)
• Transmission rates
Max. 12 Mbps
DP master
Services
• PG/OP communication
Yes
• Routing
Yes
• Global data communication
No
• S7 basic communication
No
• S7 communication
No
• Constant bus cycle time
Yes
• SYNC/FREEZE
Yes
• DPV1
Yes
Transmission speed Up to 12 Mbps
Number of DP slaves 124
DP slave
Services
• Routing
Yes (only if interface is active)
• Global data communication
No
• S7 basic communication
No
• S7 communication
No
• Direct data exchange
Yes
• Transmission rates
Up to 12 Mbps
• Automatic baud rate search
Yes (only if interface is passive)
• Intermediate memory
244 bytes I / 244 bytes O
• Address areas
max. 32 with max. 32 bytes each
• DPV1
No
2nd interface
Type of interface PROFINET
Physics Ethernet
electrically isolated Yes
Autosensing (10/100 Mbps) Yes

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
