5 Statistics/export 03/2013
5.1 Multi-machine views
© Siemens AG 2006-2012 All Rights Reserved
5-246 SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
Function Description
Representation
Duration The time frame to be examined as a time series in the display
can be adjusted. You can select certain defined periods or a
period limited by two marks in the displayed diagram.
Set marker Double-click to set two marks in the representation as time
series. These marks specify the individual characteristic
values at this point in time and serve to define a time period or
a point in time.
Defining a point in time (with machine series)
In the display as machine series, you can define the reference
time. You can enter the point in time explicitly or use one of
the two marks.
With this function, all values of the data points are exported to
an Excel file.
The data points of each data series are stored in separate
tables.
