Low-Voltage Protection Elements for 1 <--> 2
For the transition points between lightning protection zones 1 <--> 2 we
recommend the surge protection components listed in table A-4
Table A-4 Low-Voltage Protection Components for Lightning Protection Zones 1 <--> 2
Ser.
No.
Cables for ... ... equip transition point 1 <--> 2 with: Order No.
1 3-phase TN-C system 3 pieces of DEHNguard 275 surge arresters 900 600*
5SD7 030
3-phase TN-S system 4 pieces of DEHNguard 275 surge arresters 900 600*
5SD7 030
3-phase TT system 3 pieces of DEHNguard 275 surge arresters
phase L1/L2/L3 to N
900 600*
5SD7 030
1pieceof DEHNgap C N-PE surge N to PE 900 131*
AC TN-S system 2 pieces of DEHNguard 275 surge arresters 900 600*
5SD7 030
AC TN-C system 1pieceof DEHNguard 275 surge arresters 900 600*
5SD7 030
AC TT system 1pieceof DEHNguard 275 surge arresters
phase L to N
900 600*
5SD7 030
1pieceof DEHNgap C, N-PE surge
arrester, N to PE
900 131*
2 24 VDC Power Supply 1pieceof Blitzductor VT lightning
conductor, type AD 24 V
918 402*
3 Bus cable
• MPI RS 485 • Blitzductor CT surge arrester,
type MD/HF
919 506* and
919 570*
• RS 232 (V.24) 1pieceof • per conductor pair
surge arrester Blitzductor CT
type ME 15 V
919 506* and
919 522*
4 Inputs of digital modules 24
VDC
1pieceof Low-voltage surge arrester,
type FDK 2 60 V
919 993*
5 Outputs of digital modules 24
VDC
1pieceof Low-voltage surge arrester
FDK 2D5 24
919 991*
6 Inputs/outputs of digital
modules
2 pieces of Surge arresters
• 120 VAC • DEHNguard 150 900 603*
• 230 VAC • DEHNguard 275 900 600*
7 Inputs of analog modules up
to 12 V +/--
1pieceof Surge arrester
BlitzductorCTtypeMD12V
919 506* and
919 541*
* You can order these components directly at: DEHN + SÖHNE
GmbH + Co. KG
Elektrotechnische Fabrik
Hans-Dehn-Str. 1
D-92318 Neumarkt
