Siemens Simatic S7-400

Installing the S7-400
2-24
Automation System S7-400 Hardware and Installation
A5E00850741-01
2.10 Installing the Cable Duct
Procedure
1. Install the cable duct in the 19-inch pitch directly under the r ack or between two
racks. Use M6 size screws for mounting.
The following figure s hows how to mount the cable duct between two racks.
19-inch reference level
9101112131415161718
9101112131415161718
