Technical data and characteristic curves
6.1 Explanations
S-1FT7 synchronous motors
132 Configuration Manual, 09/2018, A5E45099423B AA
Permissible temperature range, characteristics S1
(100 K)
and S1
(60 K)
1FT7 motors can be operated up to an average winding temperature of 145 °C.
The S1
(100 K)
characteristic in the diagram "Torque characteristics of synchronous motors"
indicates the limits of the permissible temperature range for continuous operation. This
corresponds to a utilization according to thermal class F (155 °C).
A lower thermal class can be necessary if, for example,
the enclosure temperature must be below 90 °C for safety reasons
the motor temperature rise has a negative impact on the machine
In this case, choose the S1
(60 K)
characteristic. The motor now corresponds to thermal class
B (130 °C).
NOTICE
Motor damage caused by overheating
Continuous operation outside the permissible temperature range can result in the motor
overheating and cause damage to the motor.
Operate the motor continuously only within the S1(100 K) characteristic.
Periodic intermittent duty, characteristics S3
25 %, S3 40 %, S3 60 % and M
max
In periodic intermittent duty, you can apply a higher load to the motor, depending on the ON
duration, see also Chapter "Procedure when engineering (Page 108)".
Review the S3 characteristics with the 25 %, 40 % and 60 % ON durations.
The cycle time is always 10 minutes. The overtemperature is 100 K.
The exception are small motors, for which a cycle time of one minute is specified and noted
in the characteristic curves.
A transient, high overload capacity up to characteristic M
max
is available over the complete
speed range.
Recommended Motor Module
A Motor Module is recommended in Chapter "Motor overview / assignment of Motor Modules
/ power cables (Page 142)" for each motor in accordance with its stall current. The maximum
achievable torque is shown in the characteristic M
max conv
.
When configuring intermittent or overload operation, check whether a larger Motor
Module is required to provide the necessary peak current.
