Motor components and options
4.2 Options
S-1FT7 synchronous motors
Configuration Manual, 09/2018, A5E45099423B AA
81
Note
If more than 2 options are ordered, no options will appear on line 2.
In this case, specify the motor ID (No.YF) when ordering more motors of the same ty
pe.
The following options can also be ordered. They are a part of the article number.
● Flange "compact", recessed flange
● Shaft extension on DE with feather key and keyway (half-key balancing)
● Integrated holding brake
● Degree of protection IP65 or IP67
● Vibration severity grade R
● Radial eccentricity, concentricity and axial eccentricity: Tolerance R
● A terminal box version is alternatively possible for motors with connector size 3
Additional information is provided in Chapter "Selection based on the article number
(Page 33)".
