Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
Manual, 02/2012
83
Digital inputs
Table 4- 14 Digital inputs on SIMOTION D4x5-2
Data SIMOTION D4x5-2
Digital inputs 12
• Rated value
24 VDC
• For signal "1"
15 ... 30 V
• For signal "0"
2)
-3 ... +5 V
Galvanic isolation Yes, in groups of 6
1)
Current consumption typ. at signal level "1" 9 mA at 24 V
Input delay, typ. (hardware) L -> H: 50 µs
H -> L: 150 µs
1)
Reference potential is terminal M1 or M2
2)
The digital inputs are protected against polarity reversal up to -30 V
Digital I/Os (parameterizable)
Table 4- 15 Digital I/Os on SIMOTION D4x5-2
Data SIMOTION D4x5-2
Digital I/Os 16
• Max. 16 as inputs of measuring inputs
• Max. 8 as cam outputs
If used as an input
• Input voltage, rated value
24 VDC
• Input voltage, for signal "1"
15 ... 30 V
• Input voltage, for signal "0"
2)
-3 ... +5 V
Galvanic isolation No
Current consumption typ. at signal level "1" 9 mA at 24 V
Input delay, typ. (hardware) L -> H: 5 µs
H -> L: 50 µs
Measuring input, resolution 1 µs
Measuring input, reproducibility 5 µs
If used as an output
• Rated load voltage, permissible range
24 VDC, 20.4 ... 28.8 V
• Galvanic isolation
No
• Current load, max.
500 mA per output
• Residual current, max.
2 mA
• Output delay, typ./max. (hardware)
1)
L -> H: 150/400 µs
H -> L: 75/150 µs
