Technical data of the D4x5-2
4.5 Interfaces and performance features
SIMOTION D4x5-2
84 Manual, 02/2012
Data SIMOTION D4x5-2
• Output cam, resolution
terminal X142
1 µs
• Output cam, reproducibility terminal X142
10 µs
Switching frequency of the outputs, max.
• With resistive load
100 Hz
• With inductive load
2 Hz
• With lamp load
11 Hz
Short-circuit protection Yes
1)
Specification for Vcc = 24 V, load 48 Ohm, H = 90% V
Out
; L = 10% V
Out
2)
The digital inputs are protected against polarity reversal up to -30 V
Further technical data
Table 4- 16 Fan, non-volatile data backup and approvals
Data SIMOTION D425-2 DP
SIMOTION D425-2 DP/PN
SIMOTION D435-2 DP
SIMOTION D435-2 DP/PN
SIMOTION D445-2 DP/PN
SIMOTION D455-2 DP/PN
Fan Double fan/battery module is included
in the scope of delivery
Double fan/battery module is
included in the scope of delivery
• Backup time, min.
• Charging time,
typ.
• 4 days (real-time clock buffering)
• A few minutes
• 4 days (real-time clock buffering)
• A few minutes
• Approvals
cULus
(E164110 file)
cULus
(E164110 file)
• Marking for
Australia
C-Tick mark
C-Tick mark
If a double fan/battery module is used with included battery, the backup time of the real-time
clock is at least three years.
For further technical data, such as the maximum number of online connections, HMI devices
that can be used and a list of tasks available in the execution system, for example, see the
function overview in Catalog PM 21, Motion Control SIMOTION, SINAMICS S120 and
motors for production machines.
To Next Page
