SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
13
Description
1
1.1 System overview
Overview
SIMOTION D is a drive-based version of SIMOTION based on the SINAMICS S120 drive
family.
With SIMOTION D, the SIMOTION PLC and motion control functionalities as well as the
SINAMICS S120 drive software run on shared control hardware.
SIMOTION D is available in two versions:
● SIMOTION D410-2 is a compact control unit predestined for single-axis applications. The
control unit is snapped directly on to the SINAMICS S120 PM340 power modules in
blocksize format and has an integrated drive control for either one servo, one vector or
one
V/f
axis.
● SIMOTION D4x5-2 is a control unit for multi-axis applications in the SINAMICS S120
booksize format. The following performance versions are offered:
– SIMOTION D425-2 (BASIC performance) control unit for up to 16 axes
– SIMOTION D435-2 (STANDARD performance) control unit for up to 32 axes
– SIMOTION D445-2 (HIGH performance) control unit for up to 64 axes
– SIMOTION D455-2 (ULTRA-HIGH performance) control unit for up to 128 axes or
applications with very short control cycles
The SIMOTION D4x5 2 is described in this manual. Separate manuals are available for the
SIMOTION D410-2 and the D4x5/D410 predecessor modules.
Like SINAMICS S120, SIMOTION D also follows the Totally Integrated Automation (TIA)
concept. TIA is characterized by integrated data management, configuration, and
communication for all products and systems. Thus, an extensive toolbox of automation
modules is also available for SIMOTION D.
Note
In order to cover all versions of SIMOTION D for multi-axis applications, the product will be
referred to as "D4x5-2". Specific product designations will be used for information that
applies only to one product version, e.g. D445-2 DP/PN.
SIMOTION D4x5-2 DP describes all PROFIBUS versions and SIMOTION D4x5-2 DP/PN all
PROFIBUS/PROFINET versions of the SIMOTION D4x5-2 control units.
