Diagnostics
8.2 Diagnostic data and non-volatile SIMOTION data
SIMOTION D4x5-2
360 Commissioning and Hardware Installation Manual, 02/2012
Various options are available to you for backing up diagnostics data:
● Backing up during operation (in STOP/STOPU/RUN mode); see Section Procedure for
backin
g up during operation (Page 361)
– With IT DIAG;
IT DIAG als
o offers the option of retrieving diagnostics data online
– Via the DIAG button
– Via the Service selector switch
● Backing up while the module is starting up; for details, see Section Procedure for backing
up duri
ng startup (Page 363).
– Via the DIAG button
– Via the Servi
ce selector switch
– Control of the diagnostics data creation using an INI file stored on the CF card
8.2.2.2 Non-volatile SIMOTION data (retain data)
In addition to the diagnostic data, non-volatile SIMOTION data (retain data) is also saved on
the CompactFlash card. You can use these in situations where the non-volatile SIMOTION
data has not been saved on the CompactFlash card using the _savePersistentMemoryData
system function, and you wish to restore the non-volatile SIMOTION data after a CPU has
been replaced.
Note
While the non-volatile SIMOTION data is stored as a "PMEMORY.XML" backup file in the
"...USER\SIMOTION" directory using the _savePersistentMemoryData system function,
backing up diagnostic data and non-volatile SIMOTION data stores the data in the
"...\USER\SIMOTION\HMI\SYSLOG\DIAG directory.
