Diagnostics
8.2 Diagnostic data and non-volatile SIMOTION data
SIMOTION D4x5-2
370 Commissioning and Hardware Installation Manual, 02/2012
8.2.5 Backing up diagnostics data and non-volatile SIMOTION data using IT DIAG
SIMOTION devices feature pre-configured, standard IT DIAG pages. These pages can be
displayed via Ethernet using a commercially available browser. Additionally, you have the
option of creating your own HTML pages and incorporating service and diagnostic
information.
You can also use IT DIAG to back up diagnostics data and non-volatile SIMOTION data.
IT DIAG is opened by entering the IP address of the SIMOTION device in the address bar of
the browser; e.g. http://169.254.11.22
This opens the IT DIAG start screen. To back up diagnostic data and non-volatile SIMOTION
data, call the "Diagnostic files" page from the "Diagnostics" menu.
Figure 8-9 IT DIAG
