7.5 SIMOTION CompactFlash card
SIMOTION D4x5-2
342 Commissioning and Hardware Installation Manual, 02/2012
7.5 SIMOTION CompactFlash card
7.5.1 Changing the CompactFlash card
Requirement
CAUTION
The CompactFlash card may only be inserted or removed when the system is de-
energized. The SIMOTION D4x5-2 is in a de-energized state when all the LEDs are off.
Procedure
To change the CompactFlash card, proceed as follows:
1. Switch off the power supply.
2. Remove the CompactFlash card from the plug-in slot of the control unit.
3. Gently insert the new CompactFlash card into the empty plug-in slot until it clicks into
place. The direction of insertion of the CompactFlash card is indicated by an arrow
located on both the plug-in slot and the CompactFlash card.
When properly installed, the card does not extend beyond the housing of the
SIMOTION D4x5-2.
4. Switch the power supply on again.
7.5.2 Writing to the the CompactFlash card
Overview
You can write to the CF card by:
● Writing to the CF card inserted into a SIMOTION D
This function requires the connection to be established between the PG/PC and the
module.
● Writing to the CF card without a SIMOTION D module
For this function, you need a CF card adapter.
Note
The CF card always comes formatted. It contains the SIMOTION Kernel (SIMOTION D
firmware).
To ensure that the CF card functions properly, the card must not be repartitioned.
