Diagnostics
8.2 Diagnostic data and non-volatile SIMOTION data
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
371
Table 8- 14 Functions on the "Diagnostic files" HTML page
Button Function
Create general diagfiles This button saves diagnostic data and non-volatile SIMOTION data in
the ...\USER\SIMOTION\HMI\SYSLOG\DIAG directory. HTML files
used for diagnostics purposes are not saved.
Create html diagfiles This button is used to save HTML diagnostics pages on the data
carrier. It should be noted that only those pages that are listed in the
DIAGURLS.TXT file in directory
...\USER\SIMOTION\HMI\SYSLOG\DIAG are backed up, see Section
Diagnostics via HTML pages (Page 367).
Zip all diagfiles The "zip all Diagfiles" button enables you to compress diagnostics
files. This stores all files and folders in a ZIP file in directory
...\USER\SIMOTION\HMI\SYSLOG\DIAG, while retaining the folder
structure.
Get diagarchive This button is used to save the ZIP archive to connected PGs/PCs.
Delete all diagfiles This button is used to delete all data stored in the
...\USER\SIMOTION\HMI\SYSLOG\DIAG directory; the directory itself
is not removed, however.
You can find diagnostic data and non-volatile SIMOTION data on the CompactFlash card in
the following directory:
\USER\SIMOTION\HMI\SYSLOG\DIAG
Additional references
For detailed information, refer to the SIMOTION IT Ethernet-Based HMI and Diagnostic
Functions
Diagnostics Manual.
