Commissioning (software)
6.2 Performing the configuration for the D4x5-2 offline
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
163
2. In the "Insert Infeed" dialog box", select whether you want to use an infeed with or without
a DRIVE-CLiQ connection. If the DC link has an external supply, select "No" (no
DRIVE-CLiQ connection).
Figure 6-2 Selecting an infeed with DRIVE-CLiQ connection
Note
If you have selected an uncontrolled infeed without a DRIVE-CLiQ connection, omit steps
3 to 6 below.
