Connecting
3.9 Connecting PROFINET IO components
SIMOTION D4x5-2
76 Commissioning and Hardware Installation Manual, 02/2012
Table 3- 7 Connector types for PROFINET
Connectors Designation Order number
IE FC RJ45 plug 145 RJ45 FastConnect connector for
Industrial Ethernet/PROFINET with 145°
cable outlet
• 1 pack = 1 unit
• 1 pack = 10 units
6GK1 901-1BB30-0AA0
6GK1 901-1BB30-0AB0
Table 3- 8 Cable types for PROFINET
Cable Designation Order number
IE FC Cable GP 2x2 (Type A) 4-wire, shielded TP installation cable for
IE FC RJ45
6XV1 840-2AH10
IE FC Flexible Cable GP 2x2
(Type B)
4-wire, shielded flexible TP installation
cable for IE FC RJ45
6XV1 870-2B
IE FC Trailing Cable GP 2x2
(Type C)
4-wire TP installation cable for trailing
cable use
6XV1 870-2D
IE FC Trailing Cable 2x2
(Type C)
4-wire, shielded TP installation cable for
connection to FC OUTLET RJ45, for
trailing cable use
6XV1 840-3AH10
IE FC Marine Cable 2x2 4-wire, shielded marine-certified TP
installation cable for connection to
FC OUTLET RJ45
6XV1 840-4AH10
Table 3- 9 Stripping tool for Industrial Ethernet / PROFINET
Tool Designation Order number
IE FC Stripping Tool Stripping tool for Industrial
Ethernet / PROFINET
6GK1 901-1GA00
Additional references
For further information about the cables, connectors and stripping tool, see the
Industrial Communication IK PI Catalog.
