5 Functional Mechanisms of this Application
5.1 Functionality of process data exchange
SINAMICS G120 DP at S7-1200
Entry-ID: 70155469, V1.4, 07/2018
36
 Siemens AG 2018 All rights reserved
Networks
Table 5-2: Networks of the “Process_Data” FB
Network
Function
1.
The temporary data area #InData is initialized with 0.
2.
The process data is copied from the I/O area into the temporary #InData data
area using the “DPRD_Dat” instruction.
3.
Status word, warning and faults are copied from the temporary #InData data
area to the respective block outputs, and the current actual values [WORD]
are copied into temporary tags [INT] for data type adjustment.
4.
5.
The current normalized speed value [INT] is denormalized by calling FC11
[REAL, rpm].
6.
The current normalized current value [INT] is denormalized by calling FC11
[REAL, A].
7.
The current torque value [INT] is denormalized by calling FC11 [REAL, Nm].
8.
The setpoint speed value [REAL, rpm] is denormalized by calling FC12 [INT].
9.
Control word and normalized setpoint speed value [INT] are copied to the
temporary #OUTData data area. The remaining four words to be transferred
are written with 0.
10.
11.
The process data is copied from the temporary #OutData data area into the
I/O area using the “DPWR_DAT” instruction.

Siemens SINAMICS G120P Specifications

General

Frequency Range	0 Hz to 550 Hz
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
Output Voltage	0V to input voltage
Control Type	Vector control, V/f control
Protection Class	IP20, IP55
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Cooling Method	Air cooling
Altitude	Up to 2000 m without derating
Power Range	0.37 to 630 kW
