Siemens SINAMICS G120P Manual

4 Operating the Application
4.4 Operator Control and Monitoring via monitoring table
SINAMICS G120 DP at S7-1200
Entry-ID: 70155469, V1.4, 07/2018
27
Copyright  Siemens AG 2018 All rights reserved
Figure 4-8: Display of fault buffer message in plain text
The message text is displayed for as long as the message number is pressed.
4.4 Operator Control and Monitoring via monitoring table
You can also use the application without HMI panel. The watch tables
“Process_data” and “Parameters” have already been created in the project. The
tags you can monitor or control are the same which are also displayed or controlled
at the operator panel.
Table 4-4: Operation of the application via watch table
No.
Action
Remarks
1.
In the TIA Portal project you open the
desired watch table.

Siemens SINAMICS G120P Specifications

General

Frequency Range	0 Hz to 550 Hz
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
Output Voltage	0V to input voltage
Control Type	Vector control, V/f control
Protection Class	IP20, IP55
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Cooling Method	Air cooling
Altitude	Up to 2000 m without derating
Power Range	0.37 to 630 kW
