6 Configuration and Settings
6.1 Creating the project configuration
SINAMICS G120 DP at S7-1200
Entry-ID: 70155469, V1.4, 07/2018
45
 Siemens AG 2018 All rights reserved
6 Configuration and Settings
6.1 Creating the project configuration
Note
 If you only wish to download and commission the example program,
please follow the instructions in chapter 3 “Setting up and commissioning
the application”
 The procedure described in the step table below represents one option
of configuring a SIMATIC S7-1200 and parameterizing a SINAMICS
G120 DP for data exchange between SIMATIC controller and SINAMICS
drive. TIA Portal offers several possible solutions that differ to a greater
or lesser degree from the procedure shown here.
The step tables below describe what to do if you do not want to use the example
code, but wish to configure the SIMATIC S7 CPU, SINAMICS G120C and the HMI
KTP600. The configuration of the SIMATIC S7-1200 and the configuration of the
HMI control panel are not subject of this chapter.
6.1.1 Configuration of the components
Table 6-1: Creating the project configuration
No.
Action
Remarks
Creating the project
1.
Open TIA Portal.
2.
If TIA Portal opens in the
Portal view, go to the bottom
left to switch to the Project
view.

Siemens SINAMICS G120P Specifications

General

Frequency Range	0 Hz to 550 Hz
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Voltage Range	200 V to 240 V, 380 V to 480 V, 500 V to 690 V
Output Voltage	0V to input voltage
Control Type	Vector control, V/f control
Protection Class	IP20, IP55
Communication Interfaces	PROFIBUS, PROFINET, Modbus RTU
Cooling Method	Air cooling
Altitude	Up to 2000 m without derating
Power Range	0.37 to 630 kW
