Technical Appendix
SINUMERIK 801 7-2
Start-Up
_always 5000.0 0.0 plus DOUBLE
34030 REFP_MAX_CAM_DIST
mm,
deg.
Maximum distance to reference cam RESET
_always 10000.0 0.0 plus DOUBLE
34040 REFP_VELO_SEARCH_MARKER
mm/min,
rev/min
Creep speed (encoder no.) RESET
_always 300.0 0.0 plus DOUBLE
34050 REFP_SEARCH_MARKER_REVERSE
– Direction reversal to reference cams (encoder no.) RESET
_always 0 *** ***
BOOLEAN
34060 REFP_MAX_MARKER_DIST
mm,
deg.
Maximum distance to reference mark. Max. distance to 2
reference marks for distance–coded measuring systems.
RESET
_always 20.0 0.0 plus DOUBLE
34070 REFP_VELO_POS
mm/min,
rev/min
Reference point positioning velocity RESET
_always 1000.0 0.0 plus DOUBLE
34080 REFP_MOVE_DIST
mm,
deg.
Reference point distance/target point for distance–coded
system
RESET
_always –2.0 – – DOUBLE
34090 REFP_MOVE_DIST_CORR
mm,
deg.
Reference point offset/absolute offset distance–coded POWER ON
_always 0.0 – – DOUBLE
34092 REFP_CAM_SHIFT
mm,
deg.
Electr. cam offset of incremental measuring systems with
equidistant zero marks
RESET
_always 0.0 0.0 plus DOUBLE
34100 REFP_SET_POS
mm,
deg.
Reference point value/irrelevant for distance–coded
system: 0 ... 3
RESET
_always 0., 0., 0., 0. – – DOUBLE
34110 REFP_CYCLE_NR
– Sequence of axes in channel–specific referencing
–1: No obligatory reference point for NC Start
0: No channel–specific reference–point approach
1–15: Sequence in channel–specific reference point
approach
RESET
