Technical Appendix
SINUMERIK 801 7-2
Start-Up
_always 5, 5,10, 20, 40, 80 0.0 plus DOUBLE
35150 SPIND_DES_VELO_TOL
Factor Spindle speed tolerance RESET
_always 0.1 0.0 1.0 DOUBLE
35160 SPIND_EXTERN_VELO_LIMIT
rev/min Spindle speed limitation from PLC NEW CONF
_always 1000 0.0 plus DOUBLE
35200 GEAR_STEP_SPEEDCTRL_ACCEL
rev/s^2 Acceleration in speed control mode [gear stage no.]: 0 ...
5
NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE
35210 GEAR_STEP_POSCTRL_ACCEL
rev/s^2 Acceleration in position control mode (gear stage no.):
1 ... 5
NEW CONF
_always 30, 30, 25, 20, 15, 10 2 *** DOUBLE
35220 ACCEL_REDUCTION_SPEED_POINT
Factor Speed for reduced acceleration RESET
_always 1.0 0.0 1.0 DOUBLE
35230 ACCEL_REDUCTION_FACTOR
Factor Reduced acceleration RESET
_always 0.0 0.0 0.95 DOUBLE
35240 ACCEL_TYPE_DRIVE
– Type of acceleration RESET
0 0 1
BOOLEAN
35300 SPIND_POSCTRL_VELO
rev/min Position control switch–on speed NEW CONF
_always 500 0.0 plus DOUBLE
35350 SPIND_POSITIONING_DIR
– Direction of rotation when positioning RESET
_always 3 3 4 BYTE
35400 SPIND_OSCILL_DES_VELO
rev/min Reciprocation speed NEW CONF
_always 500 0.0 plus DOUBLE
35410 SPIND_OSCILL_ACCEL
rev/s^2 Acceleration during reciprocating NEW CONF
_always 16 2 *** DOUBLE
35430 SPIND_OSCILL_START_DIR
- Starting direction during reciprocation
0-2: As last direction of rotation (zero-speed
RESET
