Technical Appendix
7-1 SINUMERIK 801
Start-Up
M3)
3: M3 direction
4: M4 direction
_always 0 0 4 BYTE
35440 SPIND_OSCILL_TIME_CW
s Reciprocation time for M3 direction NEW CONF
_always 1.0 0.0 plus DOUBLE
35450 SPIND_OSCILL_TIME_CCW
s Reciprocation time for M4 direction NEW CONF
_always 0.5 0.0 plus DOUBLE
35500 SPIND_ON_SPEED_AT_IPO_START
- Feed enable for spindle in setp. Range RESET
_always 1 0 2 BYTE
35510 SPIND_STOPPED_AT_IPO_START
– Feedrate enable for spindle stopped RESET
_always 0 *** ***
BOOLEAN
36000 STOP_LIMIT_COARSE
mm,
deg.
Exact positioning coarse NEW CONF
_always 0.04 0.0 plus DOUBLE
36010 STOP_LIMIT_FINE
mm,
deg.
Exact positioning fine NEW CONF
_always 0.01 0.0 plus DOUBLE
36020 POSITIONING_TIME
s Delay exact positioning fine NEW CONF
_always 1.0 0.0 plus DOUBLE
36030 STANDSTILL_POS_TOL
mm,
deg.
Zero–speed tolerance NEW CONF
0.2 0.0 plus DOUBLE
36040 STANDSTILL_DELAY_TIME
s Delay zero–speed monitoring NEW CONF
_always 0.4 0.0 plus DOUBLE
36050 CLAMP_POS_TOL
mm,
deg.
Clamping tolerance NEW CONF
_always 0.5 0.0 plus DOUBLE
36060 STANDSTILL_VELO_TOL
mm/min, Maximum velocity/speed “axis/spindle stopped” NEW CONF
